Rolls-Royce welcomes Prime Minister

Rolls-Royce hosted Prime Minister Rishi Sunak and MP for Filton and Bradley Stoke, Jack Lopresti MP, at its UK defence headquarters in Bristol earlier this month. The Prime Minister met with engineers, technicians and apprentices from across the business’ defence programmes and discussed how the organisation is committed to sustaining and developing critical key skills to provide high-quality careers for decades to come.

During the visit, the Prime Minister toured the facility where he met with the highly skilled workforce, who are supporting the UK’s operational needs and developing cutting edge technologies. While at the Bristol site, the Prime Minister opened FutureWorks, a new facility where Rolls-Royce teams are developing new technologies, advanced manufacturing strategies and skills to improve the resilience of existing fleets and power the capabilities of tomorrow.

For further information www.rolls-royce.com

HELICAL ADDS COMPACT NAKAMURA TO PLANT LIST

Finding a manufacturer with its own museum is unusual to say the least, but such is the passion for manufacturing at Helical Technology that the company has a locomotive, a Red Arrow and a Bluebird replica among other artefacts at one of its four facilities. This passion for manufacturing, precision and quality is why the company has added yet another Nakamura-Tome turn-mill centre from the Engineering Technology Group (ETG) to its plant list.

Established by James Morris in 1962, the family business is a manufacturer of valve rotators used in the marine, locomotive, mining, automotive and power generation sectors. The Lytham-based company undertakes the complete design, manufacture, assembly and testing of its products, which also include prototype exhausts for high-performance vehicles and actuators for leading OEMs worldwide.

Helical’s valve rotator division was founded in 1987, today producing more than 120 different assemblies. The company expects to complete over 4 million such assemblies in 2023, making a sizeable contribution to Helical’s circa £35m turnover. Large volume production is conducted off-site, with volumes up to 1000-off produced at Lytham. It is here that Nakamura-Tome machines from ETG are delivering results.

The machine shop has 21 turning centres that include both single- and twin-spindle machines with some Y-axis capability to produce components from 16MnCr5 steel. The turning centres comprise a multitude of different brands, but when one of the largest and most prestigious brands in the world let the company down badly, Helical turned to ETG and its Nakamura machines. The company started with a Nakamura-Tome WT150II in January 2020 and built upon its success with a second WT150II and then a NTY3-100 twin-spindle, triple-turret machine.

“The difference with the WT150II compared with existing machines was like night and day,” recalls operations manager Chris Waddington. “The cycle times were 5-10% faster than the other leading machines that we had, but it was just everything else about the machine. The Nakamura was more stable, robust, user-friendly, and easy to set-up and use. So, we bought a second machine and added to it with the NTY3-100. We have some of the most productive machines in the industry, but the NTY3-100 instantly took 20-25% out of our cycle times.”

With floor space at a premium, the company followed its initial purchases with a smaller Nakamura AS200LMSY and, earlier in 2023, followed up with another Nakamura: the AS200MYS.

Production manager Jonathan Rigby says: “We had an ageing single-spindle, single-turret machine that was having reliability issues. The machine got to a point where instead of laying out on an expensive repair, we bought the Nakamura AS200MYS. The purpose was to accommodate our billet work while utilising our other machines for production runs. We wanted a compact, robust and highly productive solution and once again ETG delivered.”

Purchased to machine a family of steel valve rotator parts, typically in volumes from 200 to 2000-off, the company manually loads billets into the Nakamura AS200MYS ready for turning and heavy-duty milling. Component reloading takes place to facilitate secondary finishing operations.

“The outgoing machine was a larger footprint than the Nakamura and it had a barfeed that we didn’t need,” explains Rigby. “We wanted a compact, heavy-duty machine with a spacious work area and the Nakamura AS200MYS has certainly provided that.”

From a performance perspective, the Nakamura AS200MYS has accelerated productivity, as Rigby confirms: “The typical cycle time is 6 minutes per set-up and the Nakamura is improving our productivity by at least 15-20% compared with its predecessor. The kinematics of the machine are reducing travel and ‘fresh air’ cutting, which is shaving at least a minute off the cycle time. With the number of parts going through the Nakamura, it adds up to a major reduction. We achieve this saving through heavier cutting cycles that are credit to the rigidity and stability of the AS200MYS. With regard to milling cycles, we’re witnessing a massive reduction in cycle times. On one sleeve part we can now take a 5 mm depth of cut compared with 3 to 4 mm on the previous machine.”

He continues: “There’s less deflection and vibration, and we see a great improvement in our surface finishes. We can machine straight in at 5 mm depth of cut with no need for a finishing pass; the stability and performance of the Nakamura are that good. Although we haven’t undertaken a tool life feasibility study on this machine, we know we can produce more parts per tool and this is undoubtedly reducing our tooling consumption and costs.”

Discussing the service that Helical receives from ETG, Rigby concludes: “When our old machine was beyond repair, we needed a replacement urgently. With a short delivery lead time on the Nakamura AS200MYS, ETG loaned us a Vulcan turning centre as a stop-gap. ETG are very supportive and will always endeavour to support our business in every way possible.”

For further information www.engtechgroup.com

MACH 2024: COUNTDOWN BEGINS TO UK’s MACHINE TOOL AND MANUFACTURING TECHNOLOGY FESTIVAL

MACH 2024 is the UK’s national event for inspiring innovation and connecting the country’s manufacturing community. Taking place at the NEC in Birmingham on 15-19 April, this five-day event will feature the UK’s largest display of working machinery in a single venue.

Mills CNC (www.millscnc.co.uk), for example, says it is set to stun visitors with the size, power, speed and versatility of its large Zayer six-axis multi-tasking machining centre. One of the biggest machines Mills CNC has ever showcased at MACH, the Zayer XIOS G MT with integrated turning capabilities has X-, Y- and Z-axis travels of 4 x 1.6 x 2 m, and a sizeable 2 x 2 m worktable that can accommodate loads up to 12,000 kg. Flexible machining arrives courtesy of a 1.5 x 1.5 m built-in rotary table, a 40 kW/6000 rpm spindle, a five-axis/45° milling head and a generous -sized tool changer (up to 80 tools).

Heller (www.heller.biz) is set to promote another high-capability machine at MACH. Although not at the show, the company will prominently feature its new F 6000 five-axis mill-turn centre. The machine was launched by Heller at the EMO trade show last September. Highlights include new swivelling heads with integrated motor spindles developed in-house and an optional direct-drive torque table for performing in-cycle turning operations. A pallet changer features as standard for first-level automation, enabling the subsequent easy integration of a rotary or linear pallet storage and retrieval system.

Yamazaki Mazak (www.mazakeu.co.uk) will shine the spotlight on several new machines as part of a nine-machine line-up. Among the highlights will be the HCN-4000 NEO horizontal machining centre, which is making its UK debut. Mazak will also show its VariAxis i-800 NEO, a next-generation five-axis machining centre for fully automatic operation over extended periods. Notably, the company will also give a UK premiere to its FSW-460V, aimed at those requiring machining and friction stir welding (FSW) capability within the same working envelope. Manufacturers in the electric vehicle, semiconductor and heat transfer sectors are set to benefit.

Over on the stand of Hurco (www.hurco.co.uk), the accent will be on five-axis machining as well as the automation of vertical machining centres (VMCs). For instance, there will be a Hurco ProCobot Profeeder assisting the production of parts on a VM20i three-axis VMC and an Erowa Robot Compact 80 feeding a trunnion-type five-axis model, the VMX30Ui. The ProCobot picks and places components and removes them after machining, with the app running directly in the Max 5 control and visible on the screen. Minimal information needs entering to set a job, so changeover time can be as rapid as 30 minutes, making plug-and-play, small-batch automation a reality. The Erowa cell, on the other hand, transfers the work holding as well as the part on a pallet.

Also at MACH will be NCMT (www.ncmt.co.uk), which is celebrating its 60th anniversary this year. In 1964, it was one of the first companies to sell CNC machine tools into the UK and Irish markets when it won the sole agency to sell and service Japanese-built Makino machining centres. Some 12 years later, a second agency agreement was reached with Okuma, another Japanese machine tool manufacturer, to sell its machining centres, lathes and grinders into the same markets. NCMT will showcase both Makino and Okuma machines on its stand at MACH. Notably, the show will mark the first UK appearance of the Makino DA300 five-axis, trunnion-type VMC configured as a production cell with 40 pallet positions on five levels.

On the stand of Citizen Machinery (www.citizenmachinery.co.uk), the focus will be on the company’s proprietary LFV operating system software, which ensures efficient chip breaking. Every Citizen sliding-head turn-mill centre on the stand will have this functionality, which the company says has had a transformative effect on sales of Cincom sliders around the world, as well as selected models within Citizen’s fixed-head Miyano turning centre range. According to the company, LFV offers superior chip breaking to that achievable with conventional pecking macros and dwells. This is especially the case when machining stainless steel, aluminium, copper, various exotic materials and plastics. There is also a noticeable improvement in tool life and surface finish due to less chip re-cutting.

Continuing this technology theme, Floyd Automatic Tooling (www.floydautomatic.co.uk) will use MACH to display its cutting tool and machining solutions for the sliding-head turning and small parts machining industry. For example, new products from Mikron Tool will include the CrazyMill Cool Micro series of micro end mills. Suitable for operations as diverse as side milling, helical interpolation, slot milling and drilling, the CrazyMill Cool Micro is available in three- or four-flute options with diameters from 0.2 to 1 mm.

Another tooling specialist, Rainford Precision (www.rainfordprecision.com) is set to showcase its diverse portfolio, which includes tools for specialist applications and material types. A case in point is Hufschmied Graftor range of end mills for machining graphite. According to Rainford, the range can double productivity rates and tool life in comparison with competitor tools.

Elsewhere at the show, Industrial Tooling Corporation (www.itc-ltd.co.uk) will highlight the merits of the Big Kaiser range. By way of example, for bore machining ITC will promote the Big Kaiser EWN Monoblock series. The EWN features Smart Damper technology that reduces chatter and subsequently cycle times. EWN Monoblock fine-boring heads now include the new CK1 and CK2 products that support the machining of diameters from 20 to 36 mm and 25 to 47 mm respectively.

Software solutions will also be conspicuous at MACH. CGTech (www.cgtech.co.uk), for example, will run live demonstrations of the features in version 9.4 of its Vericut machining simulation, verification and optimisation software, and provide an exclusive preview of what is to come in version 9.5. Vericut enables users to link all machining operations end-to-end, thus evaluating and improving the entire manufacturing process.

From a metal-forming software perspective, Lantek (www.lantek.com) is set to use MACH as a showcase for advancement in the company’s latest sheet metal CADCAM and ERP suites. For example, flexibility is one of the major improvements in Lantek Expert, making it easy to move nests of parts between different machines as production requirements change without the need for manual adjustments.

Retaining the sheet metal theme, Kerf Developments (www.kerfdevelopments.com) will give UK exhibition premieres to a selection of new product lines. The new Kerf Ultra, for instance, provides both oxy/fuel and plasma cutting in a single machine platform, subsequently expanding cutting capabilities, flexibility and processing speed for users while reducing set-up time and material changeovers.

If presswork is the name of the game, then Bruderer (www.bruderer.co.uk) is the place to go. The company plans to set-up a full production line as it looks to showcase the capabilities of its energy-efficient BSTL 350-88 stamping press in the volume production of small and miniature components.

What do nearly all parts need after manufacturing? Washing. If this activity is a priority then Ecoclean (www.ecoclean-group.net) will be well worth a visit. The company will show an advanced EcoCwave machine live on its stand to illustrate the various features and process options to ensure clean parts.

For further information www.machexhibition.com

Support for MIRA expansion

In a monumental move for the Midlands, the South Site expansion at MIRA Tech Park is gaining unanimous support. The approved South Site will deliver a high-quality development incorporating 2.3m sq ft of large-scale manufacturing and industrial facilities that are complementary to the R&D facilities and campus at the existing MIRA Tech Park. This major expansion expects to create 2500 highly skilled jobs. Progress on site will receive support from power and road infrastructure investments, creating an environment conducive to growth with a range of building sizes from 250,000 sq ft to suit tenant requirements.

For further information www.miratechnologypark.com

New Kloeckner site unveiled

Kloeckner Metals UK has opened its new state-of-the-art metal stockholding and processing facility in Newbridge, Edinburgh. The site sets the stage for a transformative shift in the steel and metal processing landscape throughout the region. Boasting over 100,000 sq ft of internal space, the facility firmly establishes itself as the largest metal stockholding and processing warehouse in Scotland. The facility has a stock capacity of 5000 tonnes, made up of carbon steel, stainless steel and aluminium, coupled with Kloeckner Metals UK’s extensive processing expertise.

For further information www.kloecknermetalsuk.com
