Fast-change pallet technology

Schunk will be giving a UK exhibition premiere to its new quick-change pallet modules at the show (hall 20, stand 180). The Vero-S NSE3 138 quick-change pallet module and Vero-S NSE-T3 138 tombstone module offer an optional spring-actuated cone seal that automatically locks the module’s changing interface as soon as the clamping pin is lifted.

Schunk’s Vero-S NSE3 delivers a pull-down force of 8 kN or, with activated turbo function, 28 kN. As a result, high tilting moments and transverse forces can be absorbed when parts are clamped at the base for machining their height, for example. Clamping and positioning of the modules is carried out via a short taper with a repeat accuracy of <0.005 mm. Due to the conical fitting, the clamping pins can also be joined into the modules eccentrically. For further information www.gb.schunk.com
